Impact cratering is a process found everywhere in the solar system except on the giant gaseous planets.  Earth has been heavily impacted but erosion has removed most of the craters.

Perhaps the finest surviving impact crater on Earth is the Barringer Meteor Crater near Winslow, Arizona. It is 1.2 kilometers (0.75 miles) across and 200 meters (650 feet) deep. It was formed about 25,000 years ago when a a 50 meter (150 foot) nickel/iron meteorite struck the desert at a speed of 11 kilometers per second (25,000 miles per hour).

The Northern Moon - Click on the lunar features discussed in the Vocabulary

An examination of actual craters on the Moon will reveal that just about all craters have deep central depressions, raised rims, and a blanket of ejected material surrounding them. Try to observe the Moon directly during daylight. Observe it in the afternoon during "first quarter" and in the morning during "third quarter."

The Moon will be separated from the Sun by 90 degrees to the east (left) at first quarter and 90 degrees to the west (right) during third quarter. The large dark regions are the remains of very great impacts and many retain their circular boundaries. Binoculars on a tripod provide a spectacular view.

EXPERIMENT

You can create simulated craters with a box, lined with a trash bag, with sides at least 4 inches high (the lid to photocopier paper boxes is perfect); flour (3 to 4 inches deep with at least an inch of clearance to the box rim), some dry (powdered) tempra paint (red or blue), and some marbles.

Place the flour in the box and smooth and pack it lightly (experiment with different firmnesses). Place a dusting of the paint powder over the flour (colored water in a spray bottle works, but not as well). Use the marbles to bombard the surface (one at a time). Look for classical cratering features: basin, raised rim, ejecta blanket (material excavated from the crater and dumped around it, visible as white flour on the colored powder), and rays (material shot out at high velocity forming lines pointing directly away from the impact site).



Vocabulary:

Central Peak - A mountain found in the center of large craters. It is formed by a "rebound" of the rock at the impact site (the marble will be sitting there in this activity).

Crater - A (usually) circular depression in a surface caused by an impact.

Ejecta - Material tossed out of the crater.

Ejecta Blanket - Ejecta tossed out at low speed. The material lies like a blanket around the crater.

Floor - The interior of the crater. It is flat in large craters (the marble will be there in this activity).

Rays - Ejecta tossed out of the crater at high speed. The material forms long lines pointing directly away from the crater.

Rim - The raised edge of the crater. It is formed by the outwards and upwards compression of the crater walls, not ejecta.



11/2011
